Microservices Architecture Fundamentals: Service Mesh, API Gateway, Circuit Breaker & Distributed Tracing

This article is a comprehensive introduction to Microservices Architecture Fundamentals – including Service Mesh, API Gateway, Circuit Breaker, and Distributed Tracing with practical examples.

In a Nutshell

Microservices architecture is an approach in which an application is developed as a collection of small, independent services, each fulfilling a specific business function.

Compact Technical Description

Microservices Architecture is an architectural style that divides an application into loosely coupled, autonomously deployable services that communicate via network protocols.

Core Components:

Service Mesh

• Sidecar Pattern: Proxy next to each service
• Traffic Management: Routing, Load Balancing
• Security: mTLS, Access Control
• Observability: Metrics, Logging, Tracing
• Implementations: Istio, Linkerd, Consul Connect

API Gateway

• Single Entry Point: Centralized API access
• Request Routing: Forward requests to services
• Authentication: Authentication and authorization
• Rate Limiting: Enforce request limits
• Protocol Translation: Protocol conversion

Resilience Patterns

• Circuit Breaker: Prevent failure cascades
• Retry Pattern: Retry attempts on failures
• Timeout Pattern: Set time limits for requests
• Bulkhead Pattern: Resource isolation
• Fallback Pattern: Fallback solutions on outages

Distributed Tracing

• Request Tracing: Track requests through services
• Span Trees: Hierarchical trace structure
• Context Propagation: Propagate context
• Sampling: Data collection strategies
• Visualization: Visualize trace data

Exam-Relevant Key Points

• Microservices: Small, autonomous services with their own responsibilities
• Service Mesh: Infrastructure layer for service communication
• API Gateway: Central entry point for client requests
• Circuit Breaker: Protection mechanism against failure cascades
• Distributed Tracing: Track requests across service boundaries
• Service Discovery: Automatic detection of service instances
• Load Balancing: Distribute requests across multiple instances
• Resilience: Resistance to failures
• Chamber of Commerce Relevant: Modern distributed system architectures

Core Components

1. Service Discovery: Dynamic service detection and registration
2. API Gateway: Centralized API management and routing
3. Service Mesh: Communication control between services
4. Circuit Breaker: Error handling and isolation
5. Distributed Tracing: Request tracking and performance analysis
6. Configuration Management: Centralized configuration management
7. Monitoring: Monitoring and alerting
8. Deployment: Continuous delivery and orchestration

Practical Examples

1. Microservice with Go and Service Discovery

// main.go
package main

import (
	"context"
	"encoding/json"
	"fmt"
	"log"
	"net/http"
	"os"
	"strconv"
	"time"

	"github.com/gorilla/mux"
	"github.com/prometheus/client_golang/prometheus"
	"github.com/prometheus/client_golang/prometheus/promhttp"
	"go.opentelemetry.io/contrib/instrumentation/github.com/gorilla/mux/otelmux"
	"go.opentelemetry.io/otel"
	"go.opentelemetry.io/otel/exporters/jaeger"
	"go.opentelemetry.io/otel/sdk/resource"
	sdktrace "go.opentelemetry.io/otel/sdk/trace"
	semconv "go.opentelemetry.io/otel/semconv/v1.4.0"
	"go.opentelemetry.io/otel/trace"
	"google.golang.org/grpc"
	"google.golang.org/grpc/credentials/insecure"

	// Internal packages
	"github.com/company/microservices/internal/config"
	"github.com/company/microservices/internal/database"
	"github.com/company/microservices/internal/models"
	"github.com/company/microservices/internal/registry"
	"github.com/company/microservices/internal/circuitbreaker"
	"github.com/company/microservices/internal/tracing"
)

// Service configuration
type ServiceConfig struct {
	Name        string `json:"name"`
	Version     string `json:"version"`
	Port        int    `json:"port"`
	DatabaseURL string `json:"database_url"`
	RegistryURL string `json:"registry_url"`
	JaegerURL   string `json:"jaeger_url"`
}

// Metrics
var (
	httpRequestsTotal = prometheus.NewCounterVec(
		prometheus.CounterOpts{
			Name: "http_requests_total",
			Help: "Total number of HTTP requests",
		},
		[]string{"method", "endpoint", "status"},
	)

	httpRequestDuration = prometheus.NewHistogramVec(
		prometheus.HistogramOpts{
			Name: "http_request_duration_seconds",
			Help: "HTTP request duration in seconds",
		},
		[]string{"method", "endpoint"},
	)

	activeConnections = prometheus.NewGauge(
		prometheus.GaugeOpts{
			Name: "active_connections",
			Help: "Number of active connections",
		},
	)
)

func init() {
	prometheus.MustRegister(httpRequestsTotal)
	prometheus.MustRegister(httpRequestDuration)
	prometheus.MustRegister(activeConnections)
}

// UserService handles user-related operations
type UserService struct {
	config      *ServiceConfig
	db          *database.Database
	registry    *registry.ServiceRegistry
	tracer      trace.Tracer
	breaker     *circuitbreaker.CircuitBreaker
}

// NewUserService creates a new user service
func NewUserService(cfg *ServiceConfig) (*UserService, error) {
	// Initialize database
	db, err := database.NewDatabase(cfg.DatabaseURL)
	if err != nil {
		return nil, fmt.Errorf("failed to initialize database: %w", err)
	}

	// Initialize service registry
	reg, err := registry.NewServiceRegistry(cfg.RegistryURL)
	if err != nil {
		return nil, fmt.Errorf("failed to initialize service registry: %w", err)
	}

	// Initialize circuit breaker
	breakerConfig := circuitbreaker.Config{
		MaxRequests:     100,
		Interval:        60 * time.Second,
		Timeout:         30 * time.Second,
		ReadyToTrip:     circuitbreaker.DefaultReadyToTrip,
		OnStateChange:   circuitbreaker.DefaultOnStateChange,
		FallbackFunc:    nil,
	}

	breaker := circuitbreaker.NewCircuitBreaker(breakerConfig)

	// Initialize tracer
	tracer := otel.Tracer("user-service")

	return &UserService{
		config:   cfg,
		db:       db,
		registry: reg,
		tracer:   tracer,
		breaker:  breaker,
	}, nil
}

// RegisterService registers the service with the service registry
func (s *UserService) RegisterService(ctx context.Context) error {
	serviceInfo := registry.ServiceInfo{
		Name:      s.config.Name,
		Version:   s.config.Version,
		Address:   fmt.Sprintf("localhost:%d", s.config.Port),
		Tags:      []string{"user", "service", "v1"},
		Metadata: map[string]string{
			"port":        strconv.Itoa(s.config.Port),
			"version":     s.config.Version,
			"health_check": "/health",
		},
	}

	return s.registry.Register(ctx, serviceInfo)
}

// DeregisterService removes the service from the registry
func (s *UserService) DeregisterService(ctx context.Context) error {
	return s.registry.Deregister(ctx, s.config.Name)
}

// HealthCheck returns the health status of the service
func (s *UserService) HealthCheck(w http.ResponseWriter, r *http.Request) {
	ctx, span := s.tracer.Start(r.Context(), "health-check")
	defer span.End()

	// Check database connectivity
	if err := s.db.Ping(ctx); err != nil {
		span.SetAttributes(semconv.ExceptionMessageKey.String(err.Error()))
		w.WriteHeader(http.StatusServiceUnavailable)
		json.NewEncoder(w).Encode(map[string]string{
			"status": "unhealthy",
			"error":  err.Error(),
		})
		return
	}

	// Check circuit breaker state
	breakerState := s.breaker.State()

	w.Header().Set("Content-Type", "application/json")
	json.NewEncoder(w).Encode(map[string]interface{}{
		"status":     "healthy",
		"service":    s.config.Name,
		"version":    s.config.Version,
		"timestamp":  time.Now().Unix(),
		"breaker_state": breakerState.String(),
	})
}

// CreateUser creates a new user
func (s *UserService) CreateUser(w http.ResponseWriter, r *http.Request) {
	ctx, span := s.tracer.Start(r.Context(), "create-user")
	defer span.End()

	start := time.Now()
	defer func() {
		httpRequestDuration.WithLabelValues("POST", "/users").Observe(time.Since(start).Seconds())
	}()

	var user models.User
	if err := json.NewDecoder(r.Body).Decode(&user); err != nil {
		span.SetAttributes(semconv.ExceptionMessageKey.String(err.Error()))
		w.WriteHeader(http.StatusBadRequest)
		json.NewEncoder(w).Encode(map[string]string{"error": err.Error()})
		return
	}

	// Validate user
	if err := user.Validate(); err != nil {
		span.SetAttributes(semconv.ExceptionMessageKey.String(err.Error()))
		w.WriteHeader(http.StatusBadRequest)
		json.NewEncoder(w).Encode(map[string]string{"error": err.Error()})
		return
	}

	// Create user with circuit breaker
	result, err := s.breaker.Execute(func() (interface{}, error) {
		return s.db.CreateUser(ctx, &user)
	})

	if err != nil {
		span.SetAttributes(semconv.ExceptionMessageKey.String(err.Error()))

		if s.breaker.State() == circuitbreaker.StateOpen {
			w.WriteHeader(http.StatusServiceUnavailable)
			json.NewEncoder(w).Encode(map[string]string{
				"error": "Service temporarily unavailable",
				"code":  "CIRCUIT_BREAKER_OPEN",
			})
			return
		}

		w.WriteHeader(http.StatusInternalServerError)
		json.NewEncoder(w).Encode(map[string]string{"error": err.Error()})
		return
	}

	createdUser := result.(*models.User)

	w.Header().Set("Content-Type", "application/json")
	w.WriteHeader(http.StatusCreated)
	json.NewEncoder(w).Encode(createdUser)

	httpRequestsTotal.WithLabelValues("POST", "/users", "201").Inc()
}

// GetUser retrieves a user by ID
func (s *UserService) GetUser(w http.ResponseWriter, r *http.Request) {
	ctx, span := s.tracer.Start(r.Context(), "get-user")
	defer span.End()

	start := time.Now()
	defer func() {
		httpRequestDuration.WithLabelValues("GET", "/users/{id}").Observe(time.Since(start).Seconds())
	}()

	vars := mux.Vars(r)
	userID := vars["id"]

	if userID == "" {
		w.WriteHeader(http.StatusBadRequest)
		json.NewEncoder(w).Encode(map[string]string{"error": "User ID is required"})
		return
	}

	// Get user with circuit breaker
	result, err := s.breaker.Execute(func() (interface{}, error) {
		return s.db.GetUser(ctx, userID)
	})

	if err != nil {
		span.SetAttributes(semconv.ExceptionMessageKey.String(err.Error()))

		if s.breaker.State() == circuitbreaker.StateOpen {
			w.WriteHeader(http.StatusServiceUnavailable)
			json.NewEncoder(w).Encode(map[string]string{
				"error": "Service temporarily unavailable",
				"code":  "CIRCUIT_BREAKER_OPEN",
			})
			return
		}

		if err.Error() == "user not found" {
			w.WriteHeader(http.StatusNotFound)
			json.NewEncoder(w).Encode(map[string]string{"error": "User not found"})
			return
		}

		w.WriteHeader(http.StatusInternalServerError)
		json.NewEncoder(w).Encode(map[string]string{"error": err.Error()})
		return
	}

	user := result.(*models.User)

	w.Header().Set("Content-Type", "application/json")
	json.NewEncoder(w).Encode(user)

	httpRequestsTotal.WithLabelValues("GET", "/users/{id}", "200").Inc()
}

// UpdateUser updates an existing user
func (s *UserService) UpdateUser(w http.ResponseWriter, r *http.Request) {
	ctx, span := s.tracer.Start(r.Context(), "update-user")
	defer span.End()

	start := time.Now()
	defer func() {
		httpRequestDuration.WithLabelValues("PUT", "/users/{id}").Observe(time.Since(start).Seconds())
	}()

	vars := mux.Vars(r)
	userID := vars["id"]

	if userID == "" {
		w.WriteHeader(http.StatusBadRequest)
		json.NewEncoder(w).Encode(map[string]string{"error": "User ID is required"})
		return
	}

	var user models.User
	if err := json.NewDecoder(r.Body).Decode(&user); err != nil {
		span.SetAttributes(semconv.ExceptionMessageKey.String(err.Error()))
		w.WriteHeader(http.StatusBadRequest)
		json.NewEncoder(w).Encode(map[string]string{"error": err.Error()})
		return
	}

	user.ID = userID

	// Update user with circuit breaker
	result, err := s.breaker.Execute(func() (interface{}, error) {
		return s.db.UpdateUser(ctx, &user)
	})

	if err != nil {
		span.SetAttributes(semconv.ExceptionMessageKey.String(err.Error()))

		if s.breaker.State() == circuitbreaker.StateOpen {
			w.WriteHeader(http.StatusServiceUnavailable)
			json.NewEncoder(w).Encode(map[string]string{
				"error": "Service temporarily unavailable",
				"code":  "CIRCUIT_BREAKER_OPEN",
			})
			return
		}

		if err.Error() == "user not found" {
			w.WriteHeader(http.StatusNotFound)
			json.NewEncoder(w).Encode(map[string]string{"error": "User not found"})
			return
		}

		w.WriteHeader(http.StatusInternalServerError)
		json.NewEncoder(w).Encode(map[string]string{"error": err.Error()})
		return
	}

	updatedUser := result.(*models.User)

	w.Header().Set("Content-Type", "application/json")
	json.NewEncoder(w).Encode(updatedUser)

	httpRequestsTotal.WithLabelValues("PUT", "/users/{id}", "200").Inc()
}

// DeleteUser deletes a user by ID
func (s *UserService) DeleteUser(w http.ResponseWriter, r *http.Request) {
	ctx, span := s.tracer.Start(r.Context(), "delete-user")
	defer span.End()

	start := time.Now()
	defer func() {
		httpRequestDuration.WithLabelValues("DELETE", "/users/{id}").Observe(time.Since(start).Seconds())
	}()

	vars := mux.Vars(r)
	userID := vars["id"]

	if userID == "" {
		w.WriteHeader(http.StatusBadRequest)
		json.NewEncoder(w).Encode(map[string]string{"error": "User ID is required"})
		return
	}

	// Delete user with circuit breaker
	_, err := s.breaker.Execute(func() (interface{}, error) {
		return nil, s.db.DeleteUser(ctx, userID)
	})

	if err != nil {
		span.SetAttributes(semconv.ExceptionMessageKey.String(err.Error()))

		if s.breaker.State() == circuitbreaker.StateOpen {
			w.WriteHeader(http.StatusServiceUnavailable)
			json.NewEncoder(w).Encode(map[string]string{
				"error": "Service temporarily unavailable",
				"code":  "CIRCUIT_BREAKER_OPEN",
			})
			return
		}

		if err.Error() == "user not found" {
			w.WriteHeader(http.StatusNotFound)
			json.NewEncoder(w).Encode(map[string]string{"error": "User not found"})
			return
		}

		w.WriteHeader(http.StatusInternalServerError)
		json.NewEncoder(w).Encode(map[string]string{"error": err.Error()})
		return
	}

	w.WriteHeader(http.StatusNoContent)

	httpRequestsTotal.WithLabelValues("DELETE", "/users/{id}", "204").Inc()
}

// ListUsers retrieves a list of users with pagination
func (s *UserService) ListUsers(w http.ResponseWriter, r *http.Request) {
	ctx, span := s.tracer.Start(r.Context(), "list-users")
	defer span.End()

	start := time.Now()
	defer func() {
		httpRequestDuration.WithLabelValues("GET", "/users").Observe(time.Since(start).Seconds())
	}()

	// Parse query parameters
	page := 1
	limit := 10

	if p := r.URL.Query().Get("page"); p != "" {
		if parsed, err := strconv.Atoi(p); err == nil && parsed > 0 {
			page = parsed
		}
	}

	if l := r.URL.Query().Get("limit"); l != "" {
		if parsed, err := strconv.Atoi(l); err == nil && parsed > 0 && parsed <= 100 {
			limit = parsed
		}
	}

	// Get users with circuit breaker
	result, err := s.breaker.Execute(func() (interface{}, error) {
		return s.db.ListUsers(ctx, page, limit)
	})

	if err != nil {
		span.SetAttributes(semconv.ExceptionMessageKey.String(err.Error()))

		if s.breaker.State() == circuitbreaker.StateOpen {
			w.WriteHeader(http.StatusServiceUnavailable)
			json.NewEncoder(w).Encode(map[string]string{
				"error": "Service temporarily unavailable",
				"code":  "CIRCUIT_BREAKER_OPEN",
			})
			return
		}

		w.WriteHeader(http.StatusInternalServerError)
		json.NewEncoder(w).Encode(map[string]string{"error": err.Error()})
		return
	}

	users := result.([]*models.User)

	response := map[string]interface{}{
		"users": users,
		"pagination": map[string]interface{}{
			"page":  page,
			"limit": limit,
			"total": len(users),
		},
	}

	w.Header().Set("Content-Type", "application/json")
	json.NewEncoder(w).Encode(response)

	httpRequestsTotal.WithLabelValues("GET", "/users", "200").Inc()
}

// GetServiceInfo returns service information
func (s *UserService) GetServiceInfo(w http.ResponseWriter, r *http.Request) {
	w.Header().Set("Content-Type", "application/json")
	json.NewEncoder(w).Encode(map[string]interface{}{
		"name":       s.config.Name,
		"version":    s.config.Version,
		"port":       s.config.Port,
		"timestamp":  time.Now().Unix(),
		"breaker_state": s.breaker.State().String(),
	})
}

// MetricsHandler exposes Prometheus metrics
func (s *UserService) MetricsHandler(w http.ResponseWriter, r *http.Request) {
	promhttp.Handler().ServeHTTP(w, r)
}

// SetupRoutes configures the HTTP routes
func (s *UserService) SetupRoutes() *mux.Router {
	r := mux.NewRouter()

	// Add OpenTelemetry middleware
	r.Use(otelmux.Middleware("user-service"))

	// Add middleware for metrics and logging
	r.Use(s.metricsMiddleware)
	r.Use(s.loggingMiddleware)

	// API routes
	api := r.PathPrefix("/api/v1").Subrouter()
	api.HandleFunc("/users", s.ListUsers).Methods("GET")
	api.HandleFunc("/users", s.CreateUser).Methods("POST")
	api.HandleFunc("/users/{id}", s.GetUser).Methods("GET")
	api.HandleFunc("/users/{id}", s.UpdateUser).Methods("PUT")
	api.HandleFunc("/users/{id}", s.DeleteUser).Methods("DELETE")

	// Health and info endpoints
	r.HandleFunc("/health", s.HealthCheck).Methods("GET")
	r.HandleFunc("/info", s.GetServiceInfo).Methods("GET")

	// Metrics endpoint
	r.Handle("/metrics", promhttp.Handler()).Methods("GET")

	return r
}

// metricsMiddleware tracks HTTP request metrics
func (s *UserService) metricsMiddleware(next http.Handler) http.Handler {
	return http.HandlerFunc(func(w http.ResponseWriter, r *http.Request) {
		activeConnections.Inc()
		defer activeConnections.Dec()

		// Wrap response writer to capture status code
		wrapped := &responseWriter{ResponseWriter: w, statusCode: http.StatusOK}

		next.ServeHTTP(wrapped, r)

		// Record metrics
		httpRequestsTotal.WithLabelValues(r.Method, r.URL.Path, strconv.Itoa(wrapped.statusCode)).Inc()
	})
}

// loggingMiddleware logs HTTP requests
func (s *UserService) loggingMiddleware(next http.Handler) http.Handler {
	return http.HandlerFunc(func(w http.ResponseWriter, r *http.Request) {
		start := time.Now()

		// Wrap response writer
		wrapped := &responseWriter{ResponseWriter: w, statusCode: http.StatusOK}

		next.ServeHTTP(wrapped, r)

		duration := time.Since(start)

		log.Printf(
			"%s %s %d %v %s",
			r.Method,
			r.URL.Path,
			wrapped.statusCode,
			duration,
			r.UserAgent(),
		)
	})
}

// responseWriter wraps http.ResponseWriter to capture status code
type responseWriter struct {
	http.ResponseWriter
	statusCode int
}

func (rw *responseWriter) WriteHeader(code int) {
	rw.statusCode = code
	rw.ResponseWriter.WriteHeader(code)
}

// initTracer initializes OpenTelemetry tracing
func initTracer(serviceName, jaegerURL string) (*sdktrace.TracerProvider, error) {
	exp, err := jaeger.New(jaeger.WithCollectorEndpoint(jaeger.WithEndpoint(jaegerURL)))
	if err != nil {
		return nil, err
	}

	tp := sdktrace.NewTracerProvider(
		sdktrace.WithBatcher(exp),
		sdktrace.WithResource(resource.NewWithAttributes(
			semconv.SchemaURL,
			semconv.ServiceNameKey.String(serviceName),
			semconv.ServiceVersionKey.String("1.0.0"),
		)),
	)

	otel.SetTracerProvider(tp)
	return tp, nil
}

func main() {
	// Load configuration
	cfg, err := config.Load[ServiceConfig]("config.json")
	if err != nil {
		log.Fatalf("Failed to load configuration: %v", err)
	}

	// Initialize tracing
	tp, err := initTracer(cfg.Name, cfg.JaegerURL)
	if err != nil {
		log.Fatalf("Failed to initialize tracer: %v", err)
	}
	defer func() {
		if err := tp.Shutdown(context.Background()); err != nil {
			log.Printf("Error shutting down tracer provider: %v", err)
		}
	}()

	// Create user service
	userService, err := NewUserService(cfg)
	if err != nil {
		log.Fatalf("Failed to create user service: %v", err)
	}

	// Register service
	ctx := context.Background()
	if err := userService.RegisterService(ctx); err != nil {
		log.Fatalf("Failed to register service: %v", err)
	}

	// Setup graceful shutdown
	go func() {
		sigChan := make(chan os.Signal, 1)
		signal.Notify(sigChan, syscall.SIGINT, syscall.SIGTERM)
		<-sigChan

		log.Println("Shutting down service...")

		// Deregister service
		if err := userService.DeregisterService(ctx); err != nil {
			log.Printf("Failed to deregister service: %v", err)
		}

		// Shutdown tracer
		if err := tp.Shutdown(ctx); err != nil {
			log.Printf("Error shutting down tracer provider: %v", err)
		}

		os.Exit(0)
	}()

	// Setup routes and start server
	router := userService.SetupRoutes()

	log.Printf("Starting %s on port %d", cfg.Name, cfg.Port)
	log.Printf("Health check: http://localhost:%d/health", cfg.Port)
	log.Printf("Metrics: http://localhost:%d/metrics", cfg.Port)

	if err := http.ListenAndServe(fmt.Sprintf(":%d", cfg.Port), router); err != nil {
		log.Fatalf("Failed to start server: %v", err)
	}
}

2. API Gateway with Java Spring Cloud

// GatewayApplication.java
package com.company.gateway;

import org.springframework.boot.SpringApplication;
import org.springframework.boot.autoconfigure.SpringBootApplication;
import org.springframework.cloud.gateway.route.RouteLocator;
import org.springframework.cloud.gateway.route.builder.RouteLocatorBuilder;
import org.springframework.context.annotation.Bean;
import org.springframework.security.config.annotation.web.reactive.EnableWebFluxSecurity;
import org.springframework.security.config.web.server.ServerHttpSecurity;
import org.springframework.security.web.server.SecurityWebFilterChain;
import org.springframework.web.cors.CorsConfiguration;
import org.springframework.web.cors.reactive.CorsWebFilter;
import org.springframework.web.cors.reactive.UrlBasedCorsConfigurationSource;

import java.util.Arrays;

@SpringBootApplication
@EnableWebFluxSecurity
public class GatewayApplication {

    public static void main(String[] args) {
        SpringApplication.run(GatewayApplication.class, args);
    }

    @Bean
    public RouteLocator customRouteLocator(RouteLocatorBuilder builder) {
        return builder.routes()
                // User Service Routes
                .route("user-service", r -> r.path("/api/v1/users/**")
                        .filters(f -> f
                                .stripPrefix(2)
                                .addRequestHeader("X-Request-User-Service", "Gateway")
                                .addResponseHeader("X-Response-User-Service", "Gateway")
                                .circuitBreaker(config -> config
                                        .setName("user-service")
                                        .setFallbackUri("forward:/fallback/user-service"))
                                .retry(retryConfig -> retryConfig
                                        .setRetries(3)
                                        .setBackoff(Duration.ofMillis(100), Duration.ofMillis(500), 2))
                                .requestRateLimiter(config -> config
                                        .setRateLimiter(redisRateLimiter())
                                        .setKeyResolver(userKeyResolver()))
                        )
                        .uri("lb://user-service"))

                // Order Service Routes
                .route("order-service", r -> r.path("/api/v1/orders/**")
                        .filters(f -> f
                                .stripPrefix(2)
                                .addRequestHeader("X-Request-Order-Service", "Gateway")
                                .addResponseHeader("X-Response-Order-Service", "Gateway")
                                .circuitBreaker(config -> config
                                        .setName("order-service")
                                        .setFallbackUri("forward:/fallback/order-service"))
                                .retry(retryConfig -> retryConfig
                                        .setRetries(3)
                                        .setBackoff(Duration.ofMillis(100), Duration.ofMillis(500), 2))
                                .requestRateLimiter(config -> config
                                        .setRateLimiter(redisRateLimiter())
                                        .setKeyResolver(userKeyResolver()))
                        )
                        .uri("lb://order-service"))

                // Product Service Routes
                .route("product-service", r -> r.path("/api/v1/products/**")
                        .filters(f -> f
                                .stripPrefix(2)
                                .addRequestHeader("X-Request-Product-Service", "Gateway")
                                .addResponseHeader("X-Response-Product-Service", "Gateway")
                                .circuitBreaker(config -> config
                                        .setName("product-service")
                                        .setFallbackUri("forward:/fallback/product-service"))
                                .retry(retryConfig -> retryConfig
                                        .setRetries(3)
                                        .setBackoff(Duration.ofMillis(100), Duration.ofMillis(500), 2))
                                .requestRateLimiter(config -> config
                                        .setRateLimiter(redisRateLimiter())
                                        .setKeyResolver(userKeyResolver()))
                        )
                        .uri("lb://product-service"))

                // Notification Service Routes
                .route("notification-service", r -> r.path("/api/v1/notifications/**")
                        .filters(f -> f
                                .stripPrefix(2)
                                .addRequestHeader("X-Request-Notification-Service", "Gateway")
                                .addResponseHeader("X-Response-Notification-Service", "Gateway")
                                .circuitBreaker(config -> config
                                        .setName("notification-service")
                                        .setFallbackUri("forward:/fallback/notification-service"))
                                .retry(retryConfig -> retryConfig
                                        .setRetries(3)
                                        .setBackoff(Duration.ofMillis(100), Duration.ofMillis(500), 2))
                                .requestRateLimiter(config -> config
                                        .setRateLimiter(redisRateLimiter())
                                        .setKeyResolver(userKeyResolver()))
                        )
                        .uri("lb://notification-service"))

                // Authentication Service Routes
                .route("auth-service", r -> r.path("/api/v1/auth/**")
                        .filters(f -> f
                                .stripPrefix(2)
                                .addRequestHeader("X-Request-Auth-Service", "Gateway")
                                .addResponseHeader("X-Response-Auth-Service", "Gateway")
                                .circuitBreaker(config -> config
                                        .setName("auth-service")
                                        .setFallbackUri("forward:/fallback/auth-service"))
                                .retry(retryConfig -> retryConfig
                                        .setRetries(3)
                                        .setBackoff(Duration.ofMillis(100), Duration.ofMillis(500), 2))
                        )
                        .uri("lb://auth-service"))

                // Health Check Routes (no rate limiting)
                .route("health-check", r -> r.path("/health/**")
                        .filters(f -> f.stripPrefix(1))
                        .uri("lb://user-service"))

                .build();
    }

    @Bean
    public SecurityWebFilterChain securityWebFilterChain(ServerHttpSecurity http) {
        return http
                .csrf(ServerHttpSecurity.CsrfSpec::disable)
                .authorizeExchange(exchanges -> exchanges
                        .pathMatchers("/api/v1/auth/**").permitAll()
                        .pathMatchers("/health/**").permitAll()
                        .pathMatchers("/actuator/**").permitAll()
                        .anyExchange().authenticated()
                )
                .oauth2ResourceServer(oauth2 -> oauth2
                        .jwt(jwt -> jwt.jwtDecoder(jwtDecoder()))
                )
                .build();
    }

    @Bean
    public CorsWebFilter corsWebFilter() {
        CorsConfiguration corsConfig = new CorsConfiguration();
        corsConfig.setAllowCredentials(true);
        corsConfig.addAllowedOriginPattern("*");
        corsConfig.addAllowedHeader("*");
        corsConfig.addAllowedMethod("*");

        UrlBasedCorsConfigurationSource source = new UrlBasedCorsConfigurationSource();
        source.registerCorsConfiguration("/**", corsConfig);

        return new CorsWebFilter(source);
    }

    @Bean
    public RedisRateLimiter redisRateLimiter() {
        return new RedisRateLimiter(10, 20, 1); // replenishRate, burstCapacity, requestedTokens
    }

    @Bean
    public KeyResolver userKeyResolver() {
        return exchange -> exchange.getRequest()
                .getHeaders()
                .getFirst("X-User-ID")
                .map(userId -> (String) userId)
                .defaultIfEmpty("anonymous");
    }

    @Bean
    public JwtDecoder jwtDecoder() {
        // Configure JWT decoder based on your authentication service
        return NimbusJwtDecoder.withJwkSetUri("http://auth-service/.well-known/jwks.json").build();
    }
}

// GatewayController.java
package com.company.gateway.controller;

import org.springframework.http.HttpStatus;
import org.springframework.http.ResponseEntity;
import org.springframework.web.bind.annotation.GetMapping;
import org.springframework.web.bind.annotation.PathVariable;
import org.springframework.web.bind.annotation.RequestMapping;
import org.springframework.web.bind.annotation.RestController;
import reactor.core.publisher.Mono;

import java.util.HashMap;
import java.util.Map;

@RestController
@RequestMapping("/fallback")
public class GatewayController {

    @GetMapping("/user-service")
    public Mono<ResponseEntity<Map<String, Object>>> userServiceFallback() {
        Map<String, Object> response = new HashMap<>();
        response.put("service", "user-service");
        response.put("status", "fallback");
        response.put("message", "User service is temporarily unavailable");
        response.put("timestamp", System.currentTimeMillis());

        return Mono.just(ResponseEntity.status(HttpStatus.SERVICE_UNAVAILABLE).body(response));
    }

    @GetMapping("/order-service")
    public Mono<ResponseEntity<Map<String, Object>>> orderServiceFallback() {
        Map<String, Object> response = new HashMap<>();
        response.put("service", "order-service");
        response.put("status", "fallback");
        response.put("message", "Order service is temporarily unavailable");
        response.put("timestamp", System.currentTimeMillis());

        return Mono.just(ResponseEntity.status(HttpStatus.SERVICE_UNAVAILABLE).body(response));
    }

    @GetMapping("/product-service")
    public Mono<ResponseEntity<Map<String, Object>>> productServiceFallback() {
        Map<String, Object> response = new HashMap<>();
        response.put("service", "product-service");
        response.put("status", "fallback");
        response.put("message", "Product service is temporarily unavailable");
        response.put("timestamp", System.currentTimeMillis());

        return Mono.just(ResponseEntity.status(HttpStatus.SERVICE_UNAVAILABLE).body(response));
    }

    @GetMapping("/notification-service")
    public Mono<ResponseEntity<Map<String, Object>>> notificationServiceFallback() {
        Map<String, Object> response = new HashMap<>();
        response.put("service", "notification-service");
        response.put("status", "fallback");
        response.put("message", "Notification service is temporarily unavailable");
        response.put("timestamp", System.currentTimeMillis());

        return Mono.just(ResponseEntity.status(HttpStatus.SERVICE_UNAVAILABLE).body(response));
    }

    @GetMapping("/auth-service")
    public Mono<ResponseEntity<Map<String, Object>>> authServiceFallback() {
        Map<String, Object> response = new HashMap<>();
        response.put("service", "auth-service");
        response.put("status", "fallback");
        response.put("message", "Authentication service is temporarily unavailable");
        response.put("timestamp", System.currentTimeMillis());

        return Mono.just(ResponseEntity.status(HttpStatus.SERVICE_UNAVAILABLE).body(response));
    }
}

// GatewayFilter.java
package com.company.gateway.filter;

import org.slf4j.Logger;
import org.slf4j.LoggerFactory;
import org.springframework.cloud.gateway.filter.GatewayFilterChain;
import org.springframework.cloud.gateway.filter.GlobalFilter;
import org.springframework.core.Ordered;
import org.springframework.http.HttpHeaders;
import org.springframework.stereotype.Component;
import org.springframework.web.server.ServerWebExchange;
import reactor.core.publisher.Mono;

import java.util.UUID;

@Component
public class GatewayFilter implements GlobalFilter, Ordered {

    private static final Logger logger = LoggerFactory.getLogger(GatewayFilter.class);

    @Override
    public Mono<Void> filter(ServerWebExchange exchange, GatewayFilterChain chain) {
        // Generate unique request ID
        String requestId = UUID.randomUUID().toString();

        // Add request ID to headers
        exchange.getRequest().mutate()
                .header("X-Request-ID", requestId)
                .header("X-Gateway-Timestamp", String.valueOf(System.currentTimeMillis()));

        // Log request
        logger.info("Request: {} {} - ID: {} - User: {}",
                exchange.getRequest().getMethod(),
                exchange.getRequest().getURI(),
                requestId,
                exchange.getRequest().getHeaders().getFirst("X-User-ID"));

        // Process request and log response
        return chain.filter(exchange).then(Mono.fromRunnable(() -> {
            // Log response
            logger.info("Response: {} {} - ID: {} - Status: {}",
                    exchange.getRequest().getMethod(),
                    exchange.getRequest().getURI(),
                    requestId,
                    exchange.getResponse().getStatusCode());

            // Add response headers
            exchange.getResponse().getHeaders().add("X-Request-ID", requestId);
            exchange.getResponse().getHeaders().add("X-Gateway-Response-Time", String.valueOf(System.currentTimeMillis()));
        }));
    }

    @Override
    public int getOrder() {
        return -1; // High precedence
    }
}

// application.yml
server:
  port: 8080

spring:
  application:
    name: api-gateway
  cloud:
    gateway:
      discovery:
        locator:
          enabled: true
          lower-case-service-id: true
      routes:
        # Additional configuration can be added here
  redis:
    host: localhost
    port: 6379
    timeout: 2000ms
    lettuce:
      pool:
        max-active: 8
        max-idle: 8
        min-idle: 0

  security:
    oauth2:
      resourceserver:
        jwt:
          issuer-uri: http://auth-service

management:
  endpoints:
    web:
      exposure:
        include: health,info,metrics,prometheus,gateway
  endpoint:
    gateway:
      enabled: true

logging:
  level:
    org.springframework.cloud.gateway: DEBUG
    org.springframework.web.reactive: DEBUG
    com.company.gateway: INFO

# Resilience4j configuration
resilience4j:
  circuitbreaker:
    instances:
      user-service:
        registerHealthIndicator: true
        slidingWindowSize: 10
        minimumNumberOfCalls: 5
        permittedNumberOfCallsInHalfOpenState: 3
        automaticTransitionFromOpenToHalfOpenEnabled: true
        waitDurationInOpenState: 5s
        failureRateThreshold: 50
        eventConsumerBufferSize: 10
        recordExceptions:
          - org.springframework.web.reactive.function.client.WebClientResponseException
      order-service:
        registerHealthIndicator: true
        slidingWindowSize: 10
        minimumNumberOfCalls: 5
        permittedNumberOfCallsInHalfOpenState: 3
        automaticTransitionFromOpenToHalfOpenEnabled: true
        waitDurationInOpenState: 5s
        failureRateThreshold: 50
        eventConsumerBufferSize: 10
        recordExceptions:
          - org.springframework.web.reactive.function.client.WebClientResponseException
      product-service:
        registerHealthIndicator: true
        slidingWindowSize: 10
        minimumNumberOfCalls: 5
        permittedNumberOfCallsInHalfOpenState: 3
        automaticTransitionFromOpenToHalfOpenEnabled: true
        waitDurationInOpenState: 5s
        failureRateThreshold: 50
        eventConsumerBufferSize: 10
        recordExceptions:
          - org.springframework.web.reactive.function.client.WebClientResponseException

  retry:
    instances:
      user-service:
        maxAttempts: 3
        waitDuration: 1s
        retryExceptions:
          - org.springframework.web.reactive.function.client.WebClientResponseException
      order-service:
        maxAttempts: 3
        waitDuration: 1s
        retryExceptions:
          - org.springframework.web.reactive.function.client.WebClientResponseException
      product-service:
        maxAttempts: 3
        waitDuration: 1s
        retryExceptions:
          - org.springframework.web.reactive.function.client.WebClientResponseException

  ratelimiter:
    instances:
      user-service:
        limitForPeriod: 10
        limitRefreshPeriod: 1s
        timeoutDuration: 0
        registerHealthIndicator: true
      order-service:
        limitForPeriod: 20
        limitRefreshPeriod: 1s
        timeoutDuration: 0
        registerHealthIndicator: true
      product-service:
        limitForPeriod: 15
        limitRefreshPeriod: 1s
        timeoutDuration: 0
        registerHealthIndicator: true

3. Circuit Breaker Implementation with Python

# circuit_breaker.py
import time
import logging
from enum import Enum
from typing import Callable, Any, Optional
from functools import wraps
from dataclasses import dataclass
from threading import Lock
import asyncio

class CircuitState(Enum):
    CLOSED = "closed"
    OPEN = "open"
    HALF_OPEN = "half_open"

@dataclass
class CircuitBreakerConfig:
    max_requests: int = 100
    interval: float = 60.0  # seconds
    timeout: float = 30.0   # seconds
    expected_exception: type = Exception
    reset_timeout: float = 60.0  # seconds

class CircuitBreaker:
    def __init__(self, config: CircuitBreakerConfig):
        self.config = config
        self.state = CircuitState.CLOSED
        self.failure_count = 0
        self.last_failure_time = None
        self.success_count = 0
        self.request_count = 0
        self.lock = Lock()
        self.logger = logging.getLogger(__name__)

    def __call__(self, func: Callable) -> Callable:
        @wraps(func)
        def wrapper(*args, **kwargs):
            return self.call(func, *args, **kwargs)
        return wrapper

    def call(self, func: Callable, *args, **kwargs) -> Any:
        with self.lock:
            if self.state == CircuitState.OPEN:
                if self._should_attempt_reset():
                    self.state = CircuitState.HALF_OPEN
                    self.logger.info("Circuit breaker transitioning to HALF_OPEN")
                else:
                    raise CircuitBreakerOpenException("Circuit breaker is OPEN")

            try:
                self.request_count += 1
                result = func(*args, **kwargs)
                self._on_success()
                return result
            except self.config.expected_exception as e:
                self._on_failure()
                raise
            except Exception as e:
                self._on_failure()
                raise

    async def call_async(self, func: Callable, *args, **kwargs) -> Any:
        with self.lock:
            if self.state == CircuitState.OPEN:
                if self._should_attempt_reset():
                    self.state = CircuitState.HALF_OPEN
                    self.logger.info("Circuit breaker transitioning to HALF_OPEN")
                else:
                    raise CircuitBreakerOpenException("Circuit breaker is OPEN")

            try:
                self.request_count += 1
                if asyncio.iscoroutinefunction(func):
                    result = await func(*args, **kwargs)
                else:
                    result = func(*args, **kwargs)
                self._on_success()
                return result
            except self.config.expected_exception as e:
                self._on_failure()
                raise
            except Exception as e:
                self._on_failure()
                raise

    def _should_attempt_reset(self) -> bool:
        return (time.time() - self.last_failure_time) >= self.config.reset_timeout

    def _on_success(self):
        if self.state == CircuitState.HALF_OPEN:
            self.success_count += 1
            if self.success_count >= self.config.max_requests:
                self._reset()
        else:
            self.failure_count = 0

    def _on_failure(self):
        self.failure_count += 1
        self.last_failure_time = time.time()

        if self.state == CircuitState.HALF_OPEN:
            self.state = CircuitState.OPEN
            self.logger.warning("Circuit breaker transitioning to OPEN")
        elif self.failure_count >= self.config.max_requests:
            self.state = CircuitState.OPEN
            self.logger.warning("Circuit breaker transitioning to OPEN")

    def _reset(self):
        self.state = CircuitState.CLOSED
        self.failure_count = 0
        self.success_count = 0
        self.request_count = 0
        self.logger.info("Circuit breaker reset to CLOSED")

    def get_state(self) -> CircuitState:
        return self.state

    def get_stats(self) -> dict:
        return {
            "state": self.state.value,
            "failure_count": self.failure_count,
            "success_count": self.success_count,
            "request_count": self.request_count,
            "last_failure_time": self.last_failure_time
        }

class CircuitBreakerOpenException(Exception):
    pass

# Usage examples
def example_service():
    """Example service that can fail"""
    import random
    if random.random() < 0.3:  # 30% chance of failure
        raise ValueError("Service temporarily unavailable")
    return "Service response"

# Create circuit breaker
config = CircuitBreakerConfig(
    max_requests=5,
    interval=60.0,
    timeout=30.0,
    expected_exception=ValueError,
    reset_timeout=30.0
)

circuit_breaker = CircuitBreaker(config)

# Apply circuit breaker to service
protected_service = circuit_breaker(example_service)

# Test the circuit breaker
def test_circuit_breaker():
    for i in range(20):
        try:
            result = protected_service()
            print(f"Request {i+1}: SUCCESS - {result}")
        except CircuitBreakerOpenException as e:
            print(f"Request {i+1}: CIRCUIT BREAKER OPEN - {e}")
        except ValueError as e:
            print(f"Request {i+1}: SERVICE FAILURE - {e}")
        except Exception as e:
            print(f"Request {i+1}: UNEXPECTED ERROR - {e}")

        time.sleep(0.1)

# Async circuit breaker decorator
def circuit_breaker_async(config: CircuitBreakerConfig):
    def decorator(func):
        cb = CircuitBreaker(config)

        @wraps(func)
        async def wrapper(*args, **kwargs):
            return await cb.call_async(func, *args, **kwargs)

        return wrapper
    return decorator

# Usage with async functions
@circuit_breaker_async(config)
async def async_service():
    import random
    await asyncio.sleep(0.1)  # Simulate async operation
    if random.random() < 0.3:
        raise ValueError("Async service temporarily unavailable")
    return "Async service response"

# Test async circuit breaker
async def test_async_circuit_breaker():
    for i in range(20):
        try:
            result = await async_service()
            print(f"Async Request {i+1}: SUCCESS - {result}")
        except CircuitBreakerOpenException as e:
            print(f"Async Request {i+1}: CIRCUIT BREAKER OPEN - {e}")
        except ValueError as e:
            print(f"Async Request {i+1}: SERVICE FAILURE - {e}")
        except Exception as e:
            print(f"Async Request {i+1}: UNEXPECTED ERROR - {e}")

        await asyncio.sleep(0.1)

if __name__ == "__main__":
    logging.basicConfig(level=logging.INFO)

    print("Testing synchronous circuit breaker:")
    test_circuit_breaker()

    print("\nTesting asynchronous circuit breaker:")
    asyncio.run(test_async_circuit_breaker())

Microservices Architecture

Service Communication Patterns

graph TD
    A[Client] --> B[API Gateway]
    B --> C[Service Discovery]
    B --> D[User Service]
    B --> E[Order Service]
    B --> F[Product Service]

    C --> G[Service Registry]
    D --> H[Database]
    E --> I[Database]
    F --> J[Database]

    D --> K[Message Queue]
    E --> K
    F --> K

    K --> L[Notification Service]

    M[Service Mesh] --> D
    M --> E
    M --> F

    N[Monitoring] --> M
    O[Logging] --> M
    P[Tracing] --> M

Service Mesh Implementations

Istio vs. Linkerd vs. Consul Connect

Feature	Istio	Linkerd	Consul Connect
Complexity	High	Low	Medium
Performance	Good	Very Good	Good
Integration	Kubernetes	Kubernetes	Multi-Cloud
Security	mTLS, RBAC	mTLS	mTLS, Intentions
Observability	Jaeger, Prometheus	Grafana, Prometheus	Prometheus

Service Mesh Features

• Traffic Management: Routing, Load Balancing, Traffic Splitting
• Security: mTLS, Access Control, Certificate Management
• Observability: Metrics, Logging, Tracing
• Reliability: Retries, Timeouts, Circuit Breaking
• Policy Enforcement: Access Policies, Rate Limiting

API Gateway Patterns

Gateway Routing Strategies

Pattern	Description	Application
Routing	Forward requests to services	Load Balancing
Composition	Combine multiple services	API Composition
Protocol Translation	Protocol conversion	Legacy Integration
Aggregation	Data from multiple services	Data Aggregation

Gateway Features

• Authentication: JWT, OAuth2, API Keys
• Authorization: RBAC, Policy Enforcement
• Rate Limiting: User-based, Service-based
• Caching: Response Caching, Edge Caching
• Monitoring: Metrics, Logging, Tracing

Resilience Patterns

Circuit Breaker States

stateDiagram-v2
    [*] --> CLOSED
    CLOSED --> OPEN: Failure Threshold Reached
    OPEN --> HALF_OPEN: Reset Timeout
    HALF_OPEN --> CLOSED: Success Threshold Reached
    HALF_OPEN --> OPEN: Failure Occurs
    CLOSED --> CLOSED: Success
    OPEN --> OPEN: Reset Timeout Not Reached

Resilience Patterns Overview

Pattern	Purpose	Implementation
Circuit Breaker	Prevent failure cascades	State Machine
Retry	Overcome temporary errors	Exponential Backoff
Timeout	Avoid infinite loops	Time Limits
Bulkhead	Resource isolation	Thread Pools
Fallback	Provide alternative solutions	Alternative Services

Distributed Tracing

Trace Context Propagation

# Trace context example
class TraceContext:
    def __init__(self, trace_id: str, span_id: str, parent_span_id: str = None):
        self.trace_id = trace_id
        self.span_id = span_id
        self.parent_span_id = parent_span_id
        self.baggage = {}

    def to_headers(self) -> dict:
        return {
            "X-Trace-ID": self.trace_id,
            "X-Span-ID": self.span_id,
            "X-Parent-Span-ID": self.parent_span_id or "",
            "X-Baggage": json.dumps(self.baggage)
        }

    @classmethod
    def from_headers(cls, headers: dict) -> 'TraceContext':
        return cls(
            trace_id=headers.get("X-Trace-ID", str(uuid.uuid4())),
            span_id=headers.get("X-Span-ID", str(uuid.uuid4())),
            parent_span_id=headers.get("X-Parent-Span-ID"),
            baggage=json.loads(headers.get("X-Baggage", "{}"))
        )

Tracing Implementations

Tool	Integration	Features	Application
Jaeger	OpenTelemetry	Distributed Tracing	Microservices
Zipkin	Spring Cloud	Request Tracing	Legacy Systems
AWS X-Ray	AWS Services	Cloud Tracing	AWS Environment
Google Cloud Trace	GCP Services	Performance Analysis	GCP Environment

Advantages and Disadvantages

Advantages of Microservices

• Scalability: Scale individual services independently
• Flexibility: Different technologies per service
• Resilience: Failure of one service does not affect the entire system
• Team Autonomy: Small teams can work independently
• Faster Deployment: Small, frequent deployments

Disadvantages

• Complexity: High infrastructural complexity
• Communication Overhead: Network latencies
• Data Consistency: Distributed transactions
• Monitoring: Complex monitoring required
• Testing: End-to-end tests are complex

Common Exam Questions

1. What is the difference between Service Mesh and API Gateway? Service Mesh manages communication between services, while API Gateway manages incoming client requests and routes them to services.

2. Explain the Circuit Breaker Pattern! Circuit Breaker prevents failure cascades by blocking requests to error-prone services when a certain failure threshold is reached.

3. When do you use Distributed Tracing? Distributed Tracing is used to track requests through multiple microservices, identify performance bottlenecks, and debug errors.

4. What are the main advantages of Microservices? Independent scalability, technological flexibility, improved resilience, and faster deployment cycles.

Key Resources

1. https://istio.io/
2. https://linkerd.io/
3. https://spring.io/projects/spring-cloud-gateway
4. https://opentelemetry.io/
